Product Overview
The Schneider VW3M5A11R03GJ Power Cable Module is a high-quality connection accessory developed for Easy Lexium 16 motion control applications. Designed to connect compatible BCH16 servo motors with Easy Lexium 16 servo drives, it provides stable power transmission while simplifying installation through its factory-assembled construction.
Built for demanding industrial environments, the VW3M5A11R03GJ combines dependable electrical performance with excellent installation flexibility. Whether integrated into compact automation equipment or precision manufacturing machinery, this power cable helps maximize system reliability, reduce commissioning time, and support consistent servo performance throughout the equipment lifecycle.
Technical Specifications
| Specification | Details |
|---|
| Manufacturer | Schneider Electric |
| Model | VW3M5A11R03GJ |
| Product Type | Power Cable Module |
| Product Series | Easy Lexium 16 |
| Compatible Servo Motor | BCH16 Series |
| Compatible Servo Drive | Easy Lexium 16 |
| Cable Type | Servo Motor Power Cable |
| Cable Length | 3 m |
| Shielding | Unshielded |
| Installation | Between Servo Drive and Servo Motor |
| Dimensions | Cable Length: 3000 mm |
| Weight | Approx. 0.30 kg |
Recommended Companion Models
| Model | Product Name |
|---|
| VW3M5A11R015 | Servo Motor Power Cable |
| VW3M5A11R05 | Servo Motor Power Cable |
| LXM16DU10M2X | Easy Lexium 16 Servo Drive |
| BCH16M02A1C | BCH16 Servo Motor |
Frequently Selected Alternatives
| Model | Product Name |
|---|
| VW3M5A11R10 | Servo Motor Power Cable |
| VW3M5A12R03 | Servo Motor Brake Cable |
| VW3M4A31 | Servo Encoder Cable |
| LXM16DU07M2X | Easy Lexium 16 Servo Drive |
Technical FAQs
1. What is the primary function of the VW3M5A11R03GJ?
The VW3M5A11R03GJ is a servo motor power cable designed to provide a dependable power connection between Schneider Electric Easy Lexium 16 servo drives and compatible BCH16 servo motors.
2. Which Schneider Electric servo system is compatible with this cable?
It is intended for Easy Lexium 16 servo drives used together with BCH16 servo motors.
3. Is this cable supplied ready for installation?
Yes. The cable is factory-assembled, allowing quick installation while reducing field wiring errors.
4. Is the VW3M5A11R03GJ used for power or encoder feedback?
This model is designed for servo motor power transmission. Encoder feedback requires a dedicated encoder cable.
5. Can this cable support continuous industrial operation?
Yes. It is engineered for continuous-duty automation equipment where stable and reliable servo power delivery is required.
6. What are the benefits of using an original Schneider Electric cable?
Original Schneider Electric accessories ensure mechanical compatibility, reliable electrical performance, and seamless integration with supported motion control systems.
7. Does the cable require software configuration after installation?
No. It is a passive connection accessory and requires no programming or parameter configuration.
8. Can this cable be routed through industrial cable management systems?
Yes. When installed according to Schneider Electric recommendations and machine design requirements, it can be integrated into suitable cable routing systems.
9. Is this cable intended for Easy Lexium 32 or Lexium 62 servo systems?
No. It is specifically designed for the Easy Lexium 16 platform and compatible BCH16 servo motors.
10. Why is selecting the correct servo power cable important?
Using the specified cable helps maintain electrical reliability, simplifies installation, and supports long-term performance of the complete servo motion system.
