Product Overview
The Schneider VW3M5A21R05GJ Power Cable Module is a professional servo connection accessory developed for Easy Lexium 16D motion control systems. Designed for BCH16 servo motor applications, it provides dependable power transmission while simplifying installation in industrial automation equipment.
With its 5-meter cable length, robust connection design, and optimized power transmission capability, the VW3M5A21R05GJ offers a practical solution for machine builders, system integrators, and maintenance professionals. It is especially suitable for compact automation systems where reliable servo connectivity and efficient installation are essential.
Technical Specifications
| Specification | Details |
|---|
| Manufacturer | Schneider Electric |
| Model | VW3M5A21R05GJ |
| Product Type | Power Cable Module |
| Product Series | Easy Lexium 16D |
| Compatible Servo Drive | Easy Lexium 16D |
| Compatible Servo Motor | BCH16 Series |
| Cable Type | Servo Motor Power Cable |
| Cable Construction | 4G2.0 mm² |
| Cable Length | 5 m |
| Connection Type | Power Connection Lead |
| Application | Servo Motor Power Transmission |
| Installation | Servo Drive to Servo Motor Connection |
| Dimensions | Cable Length: 5000 mm |
| Weight | Approx. 0.80 kg |
Recommended Companion Models
| Model | Product Name |
|---|
| VW3M5A21R03 | BCH16 Servo Motor Power Cable |
| VW3M5A21R20 | BCH16 Servo Motor Power Cable |
| VW3M5A11R05 | BCH16 Servo Motor Power Cable |
| LXM16DU15M2X | Easy Lexium 16D Servo Drive |
Frequently Selected Alternatives
| Model | Product Name |
|---|
| VW3M5A11R10 | BCH16 Servo Motor Power Cable |
| VW3M8A21R05 | BCH16 Servo Motor Signal Cable |
| VW3M5A12 | Easy Lexium 16D I/O Connector |
| BCH16M02A1C | BCH16 Servo Motor |
Technical FAQs
1. What is the primary function of the Schneider VW3M5A21R05GJ?
The VW3M5A21R05GJ is a servo motor power cable accessory designed to provide a reliable power connection between Easy Lexium 16D servo drives and compatible BCH16 servo motors.
2. Which Schneider Electric product family is compatible with this cable?
The cable is designed for the Easy Lexium 16D servo system and BCH16 motor applications requiring a dedicated power connection solution.
3. Is the VW3M5A21R05GJ used for power transmission or signal communication?
The VW3M5A21R05GJ is a power cable accessory and is intended for servo motor power transmission rather than encoder feedback or communication signals.
4. What type of motor applications can use this cable?
It is suitable for BCH16 servo motor installations paired with Easy Lexium 16D servo drives.
5. Does this cable require software configuration after installation?
No. The VW3M5A21R05GJ is a passive connection accessory and does not require programming, firmware settings, or parameter configuration.
6. What advantages does a dedicated Schneider servo cable provide?
A dedicated Schneider cable ensures correct electrical matching, stable operation, and reliable integration between servo drives and motors.
7. Is this cable suitable for OEM machine building?
Yes. It is suitable for OEM equipment manufacturers and automation integrators who require consistent servo power connections.
8. Can this cable support continuous industrial operation?
Yes. It is designed for industrial automation environments where dependable servo motor power delivery is required.
9. What installation benefits does a factory-prepared cable provide?
A factory-prepared cable reduces wiring complexity, improves installation efficiency, and helps minimize connection errors during commissioning.
10. Why is selecting the correct servo power cable important?
Using the correct cable helps maintain system reliability, prevents compatibility issues, and supports stable motion control performance.
