GE IC695CHS016 16-Slot Universal Backplane Chassis for PACSystems RX3i PLC Automation
GE IC695CHS016 16-Slot Universal Backplane Chassis for PACSystems RX3i PLC Automation
0.0
Points
Brand:GE Fanuc PLC Item No.:GE IC695CHS016 Product Origin: USA Product Dimensions:584×141.5×147.3 mm Product Weight:1.9 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The GE IC695CHS016 Universal Backplane Chassis is a robust structural foundation designed for the PACSystems RX3i programmable controller series. With 16 expansion slots, this chassis supports a broad mix of CPUs, power supplies, communication modules, and I/O cards, enabling engineers to scale complex automation systems without spatial compromise.
Built with industrial reliability in mind, the IC695CHS016 provides solid mechanical support, dependable electrical connections, and flexible configuration options — making it ideal for large distributed control systems, factory automation networks, and process monitoring installations.
Technical Specifications
Specification
Details
Module Type
Universal Backplane Chassis
Series Compatibility
GE PACSystems RX3i
Available Slots
16 (supports PCI & Serial modules)
Supported Module Types
CPU, I/O, Communication, Power Supply Modules
Bus Architecture
Dual-bus (PCI + High-Speed Serial)
Mounting Orientation
Horizontal rack mounting
Required Power
+24 VDC external feed (terminal block)
Isolation Support
Backplane ground and shield support
Backplane Power Consumption
Approx. 600 mA @ 3.3 VDC; 240 mA @ 5 VDC (internal)
Operating Temperature
0°C to +60°C
Storage Temperature
−40°C to +85°C
Protection Rating
UL/NEMA Type 1 minimum (IP20), upgradeable enclosure recommended
Dimensions (L×W×H)
584×141.5×147.3 mm
Weight
Approx. 1.9 kg
The IC695CHS016 chassis is engineered for flexibility and long-term service life, supporting mixed module arrangements in high-channel and mixed I/O configurations. It ensures reliable backplane communication and power distribution across all slots.
Recommended Related Modules
GE IC695CPU320 – High-Performance CPU Module
GE IC695PWR330 – Power Supply Module
GE IC695BEM331 – Genius / Ethernet Communication Module
GE IC695ALG600 – Universal Analog Input Module
GE IC695MDL753 – 32-Point Discrete Output Module
Popular GE PACSystems Modules
GE IC695CPU315 – Standard CPU Module
GE IC695ALG608 – 8-Channel Analog Input
GE IC695ALG616 – 16-Channel Analog Input
GE IC694PWR321 – Expansion Power Supply
GE IC695ETM001 – Ethernet Transmit Module
Typical Industrial Applications
The IC695CHS016 chassis is widely used in environments where high module count, mixed I/O demands, and system scalability are key:
Large-scale process automation control systems
Centralized data acquisition in utilities and energy
Chemical and petrochemical plant control networks
Advanced manufacturing and assembly line automation
Distributed I/O system hubs in complex architectures
Its ample slot count and flexible bus support make it ideal for installations requiring a mix of CPU performance, communications, analog, and discrete I/O expansions.
Advantages
High slot capacity — supports up to 16 modules in a single chassis
Dual bus design — compatible with both PCI and high-speed serial modules
Modular flexibility — allows mixed module types without compromise
Industrial durability — engineered for dependable long-term service
Scalable architecture — supports growth and phased add-ins
Optimized layout — horizontal design enhances airflow and cooling
The IC695CHS016 provides a stable and flexible backbone for RX3i PLC installations, streamlining panel architecture and enabling robust automation strategies.
Technical FAQs
1. How many total slots does the IC695CHS016 provide?
It provides 16 expansion slots for RX3i modules.
2. What types of modules can be installed?
CPU, analog/digital I/O, communication, and power supply modules.
3. What bus architecture does it support?
It supports a dual bus structure with PCI and high-speed serial backplane.
4. Is +24 V DC required for operation?
Yes — the chassis requires an external +24 V DC feed for internal power distribution.
5. What orientation must it be mounted in?
It is designed for horizontal rack mounting to ensure correct air circulation.
6. Can modules be hot-swapped during operation?
Some modules support hot-swap; refer to specific module documentation.
7. Is backplane isolation supported?
Yes — backplane ground and shielding enhance noise rejection.
8. What industries commonly use this chassis?
Utilities, energy, chemical processing, and discrete manufacturing sectors.
9. Can the chassis support future system expansion?
Yes — its 16 slots support phased growth and mixed I/O strategies.
10. What are the physical dimensions of the chassis? 584×141.5×147.3 mm, with a weight of approximately 1.9 kg.
