The Yokogawa S9260DE (commonly referenced as S9260DE-01) is a high-density digital input/output module designed for Yokogawa CENTUM VP / CENTUM CS 3000 distributed control systems (DCS).
It functions as a bridge between field devices and the control system, enabling real-time processing of digital signals from sensors, switches, alarms, and actuators. With integrated input and output capabilities in a single module, it helps reduce panel space while improving wiring efficiency and system performance.
Engineered for demanding industrial environments, the S9260DE ensures fast response, reliable signal isolation, and long-term stability, making it a preferred choice in process automation systems.
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | Yokogawa |
| Model | S9260DE |
| Product Type | Digital Input / Output Module |
| System Compatibility | CENTUM VP / CS 3000 |
| Digital Inputs | 16 points |
| Digital Outputs | 32 points |
| Signal Voltage | 0–24 V DC |
| Communication Interface | N-ESB Bus |
| Isolation Method | Photocoupler isolation |
| Power Supply | 24 V DC |
| Operating Temperature | -20°C to +60°C |
| Withstanding Voltage | 1500 V AC (1 min) |
The module combines input sensing and output control in one compact unit, improving system efficiency and reducing hardware requirements.
Physical Characteristics
| Item | Specification |
|---|---|
| Dimensions (W × H × D) | 76 × 127 × 127 mm |
| Weight | Approx. 0.3 – 0.7 kg |
| Mounting Type | DIN rail / cabinet installation |
| Structure | Compact integrated I/O module |
| Build | Industrial-grade rugged housing |
