The Yokogawa SAV144-S33 is a 16-channel isolated analog input module designed for Yokogawa ProSafe-RS Safety Instrumented Systems (SIS) and related industrial safety control architectures.
It is used to acquire voltage-based process signals (typically 1–5 V or 1–10 V) from field instruments such as transmitters, pressure sensors, and monitoring devices. The module ensures high-accuracy data acquisition with strong electrical isolation, making it suitable for critical safety applications such as ESD, F&G, and BMS systems.
The “-S33” suffix indicates a specific hardware configuration variant, commonly associated with standard industrial temperature rating and selected installation options within the SAV144 series family.
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | Yokogawa |
| Model | SAV144-S33 |
| Product Type | Analog Input Module |
| System | ProSafe-RS / Safety Node |
| Channels | 16 channels (module isolated) |
| Input Type | Voltage input |
| Input Range | 1–5 V / 1–10 V DC |
| Permissible Input | Up to ±30 V |
| Accuracy | ±4 mV (1–5 V), ±9 mV (1–10 V) |
| Update Time | ~40 ms |
| Input Impedance | 1 MΩ (powered) / 100 kΩ (unpowered) |
| Withstand Voltage | 1.5 kV AC (1 min) |
| Power Consumption | ~300 mA @ 24 V DC |
This module is designed for high-integrity analog signal acquisition in safety-related control loops, ensuring stable performance under industrial conditions.
Physical Characteristics
| Item | Specification |
|---|---|
| Dimensions (W × H × D) | Approx. 130 × 124 × 32.8 mm |
| Weight | Approx. 0.26 – 0.33 kg |
| Mounting Type | Rack / Safety node installation |
| Structure | Plug-in modular I/O card |
| Wiring | Terminal block / MIL cable interface |
