The GE IC697ALG234 is a Series 90-70 analog input module designed for GE Fanuc PLC systems. It is used to convert real-world analog signals into digital data for industrial control applications, enabling PLC CPUs to accurately monitor process variables such as temperature, pressure, flow, and level.
Compared with earlier ALG230 series modules, the IC697ALG234 is typically positioned as a compact analog input solution for streamlined I/O configurations, making it suitable for systems where reliable signal acquisition is required with simplified hardware architecture.
Technical Specifications
The IC697ALG234 provides stable analog signal acquisition for industrial automation environments.
| Parameter | Specification |
|---|---|
| Model | IC697ALG234 |
| Product Type | Analog Input Module |
| Series | GE Fanuc Series 90-70 |
| Input Type | Analog signals |
| Channels | Typically 8 input channels (series-based configuration) |
| Signal Types | 4–20 mA / voltage input (application dependent) |
| Isolation | Backplane isolation protection |
| Function | Signal conversion (Analog → Digital) |
| Installation | PLC rack-mounted module |
| Compatibility | GE Series 90-70 PLC system |
Physical Dimensions & Weight
| Parameter | Value |
|---|---|
| Dimensions (L × W × H) | Approx. 100 mm × 100 mm × 100 mm (varies by revision & enclosure design) |
| Weight | Approx. 0.3 – 1.0 kg |
This compact modular structure allows easy integration into standard GE 90-70 PLC racks without requiring additional mounting hardware.
Recommended Related Models
For full analog and control system integration, IC697ALG234 is often used with:
- GE IC697CPU772 Central Processing Unit
- GE IC697CHS790 Rack Chassis
- GE IC697PWR711 Power Supply Module
- GE IC697BEM713 Bus Communication Module
- GE IC697ALG230 / ALG320 Analog Input Modules
These modules together form a stable and scalable industrial control architecture.
Popular GE Series 90-70 Modules
- IC697CPU780 – High-performance PLC CPU
- IC697MDL740 – Digital input module
- IC697MDL750 – Digital output module
- IC697ALG230 – High-level analog input base converter
- IC697BEM731 – Communication module
These modules are widely used in long-life industrial automation systems worldwide.
