Brand:GE Fanuc PLC Item No.:GE IC697VHD001 Product Origin: USA Product Dimensions:160 × 233 × 20 mm Product Weight:4.54 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The GE IC697VHD001 is a VMEbus-based industrial hard disk module designed for GE Fanuc Series 90-70 PLC and PAC systems. Unlike typical I/O or control modules, this device functions as a system storage unit, providing operating system and application data storage for industrial controllers.
It is widely used in legacy GE automation platforms, where reliable onboard storage is required for runtime programs, system configurations, and control logic execution support.
Technical Specifications
Parameter
Details
Manufacturer
GE Fanuc / Emerson
Series
90-70 Series
Model Number
IC697VHD001
Module Type
VME Hard Disk Storage Module
Storage Type
IDE Hard Disk Drive (HDD)
Storage Capacity
~10 GB (typical configuration)
Interface
40-pin IDE + VME backplane
Form Factor
Single-slot 6U VMEbus Eurocard
Function
System storage for PLC/PAC software
Compatibility
GE IC697 Series CPU systems
Power Supply
5V DC from VME backplane
Typical Spin-up Current
~2.5 A
Operating Temperature
5°C to 50°C
Applications
The IC697VHD001 is used in industrial control systems requiring embedded system storage, including:
GE 90-70 PLC/PAC controller platforms
Industrial automation control computers
Legacy process control systems
Power plant control and monitoring systems
Manufacturing system runtime environments
It is especially important in systems where program storage and system boot data must remain stable in industrial environments.
Advantages
Reliable Industrial Storage Solution
Designed for continuous operation in automation systems.
Integrated VMEbus Architecture
Direct compatibility with GE 90-70 rack systems.
Dedicated PLC System Storage
Stores runtime applications and system configurations.
Robust Industrial Design
Built for vibration and temperature tolerance.
Low Power Operation
Efficient power usage for embedded systems.
Stable Legacy System Support
Essential for maintaining older GE automation installations.
Technical FAQs
1. What is the IC697VHD001 used for?
It is a hard disk storage module used in GE 90-70 PLC/PAC systems.
2. Is it a control or I/O module?
No, it is a storage module.
3. What is its storage type?
IDE-based hard disk drive.
4. What is its capacity?
Approximately 10 GB in typical configurations.
5. What interface does it use?
VMEbus backplane and IDE connection.
6. What is its weight?
Around 4.54 kg.
7. Is it still used today?
Yes, mainly in legacy GE automation systems.
8. What systems is it compatible with?
GE 90-70 single-board computer and PLC systems.
9. What is its main function?
System and application data storage for industrial controllers.
10. Why is it important in automation systems?
Because it ensures reliable storage of PLC runtime software and configuration data.
