GE IC698CHS117 Rack Chassis Module

Applications

The IC698CHS117 is widely used in high-performance distributed control systems requiring scalable rack architecture, including:

• Power generation and turbine control systems
• Oil & gas refining and pipeline automation
• Large manufacturing and assembly lines
• Water treatment and utility infrastructure
• SCADA and DCS integrated control systems

It is especially suitable for systems requiring high I/O density, fast backplane communication, and long-term industrial reliability.

Advantages

• High-Density 18-Slot Architecture
  Supports complex multi-module PLC configurations.
• VME64 High-Speed Backplane
  Ensures fast and deterministic data communication.
• Strong Power Handling Capability
  Supports up to 350W system loads.
• Flexible System Expansion
  Compatible with RX7i and legacy Series 90-70 modules.
• Software-Based Configuration
  Eliminates manual jumpers and DIP switch setup.
• Industrial-Grade Durability
  Designed for continuous 24/7 operation in harsh environments.

Technical FAQs

1. What is the IC698CHS117 used for?
It is the main rack chassis used to mount and connect PLC modules.

2. How many slots does it have?
It provides 18 slots for CPU, I/O, and communication modules.

3. What is its backplane type?
It uses a high-speed VME64 backplane system.

4. What is its weight?
Approximately 5.9 kg.

5. What is its power capacity?
Up to 350W depending on configuration.

6. Is cooling required?
Optional fan is recommended for high-load systems.

7. What systems is it compatible with?
GE PACSystems RX7i and some Series 90-70 modules.

8. Is it an I/O module?
No, it is a rack chassis (system backbone).

9. What industries use it most?
Power, oil & gas, manufacturing, and utilities.

10. Why is it important in automation systems?
Because it provides the structural, electrical, and communication foundation for the entire PLC system.
