Brand:GE Fanuc PLC Item No.:GE IC200ALG322 Product Origin:USA Product Dimensions:263 × 58 × 28 mm Product Weight:0.31 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The GE IC200ALG322 is a high-performance VersaMax analog output module designed for industrial automation systems that require precise and stable voltage control. It converts PLC digital commands into analog voltage outputs for real-world control devices, making it essential in closed-loop process automation.
With 4 independent output channels and fast update capability, it is widely used in manufacturing, process control, and machine automation systems where accuracy, responsiveness, and signal stability directly impact production quality.
This module is known for its reliable signal retention behavior, strong isolation, and industrial-grade durability, making it a trusted component in GE distributed control architectures.
Technical Specifications
Parameter
Details
Manufacturer
GE Fanuc / Emerson
Series
VersaMax PLC System
Model Number
IC200ALG322
Module Type
Analog Output Module
Output Channels
4 single-ended channels
Output Signal Range
-10.24 VDC to +10.24 VDC
Resolution
12-bit precision
Update Rate
0.3 ms high-speed response
Output Load
Resistive load up to ~5 kΩ
Field Power Supply
18–30 VDC external supply required
Backplane Power
5 VDC logic supply
Backplane Consumption
~50 mA
Output Data Format
4 words per module
Signal Retention
Hold last state or default selectable
Isolation
250 VAC continuous / 1500 VAC for 1 min
Diagnostic LEDs
FLD PWR, OK
Operating Temperature
0°C to 60°C
Applications
The IC200ALG322 is widely used in precision analog control systems, including:
Industrial valve and actuator positioning
Process control loops (pressure, flow, temperature regulation)
HVAC and building automation systems
Chemical dosing and mixing systems
Variable speed drive control interfaces
OEM machinery automation
It is especially effective in environments where stable analog voltage output is critical for smooth and accurate process behavior.
Advantages
High-Precision 12-bit Output Control
Ensures accurate analog signal generation.
Fast 0.3 ms Response Time
Supports real-time industrial control systems.
4 Independent Output Channels
Enables multi-device control in compact design.
Signal Retention Functionality
Maintains last output state during communication loss.
Strong Industrial Isolation
Protects system from electrical disturbances.
Stable VersaMax Integration
Seamless compatibility with GE PLC architectures.
Technical FAQs
1. What is the IC200ALG322 used for?
It is used to output analog voltage control signals from a PLC to industrial devices.
2. How many output channels does it have?
It has 4 analog output channels.
3. What is its output range?
-10.24 VDC to +10.24 VDC.
4. What is its resolution?
12-bit resolution.
5. What is its update speed?
Approximately 0.3 ms per update cycle.
6. Does it require external power?
Yes, 18–30 VDC field supply is required.
7. What devices can it control?
Valves, actuators, VFDs, dampers, and industrial controllers.
8. What happens during power loss?
It can hold last output or switch to default state depending on configuration.
9. What is its weight?
Approximately 0.14–0.31 kg.
10. Why is it important in automation systems?
Because it provides precise, stable analog control signals essential for process regulation.
