Brand:GE Fanuc PLC Item No.:GE IC200ALG325 Product Origin:USA Product Dimensions:160 × 80 × 80 mm Product Weight:0.63 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The GE IC200ALG325 is a VersaMax high-density analog output module designed for GE Fanuc distributed control and automation systems. It provides 8 channels of precise analog voltage output, enabling PLC systems to control field devices such as actuators, valves, drives, and process regulators.
This module is engineered for stable industrial signal generation with high resolution and strong electrical isolation, making it a reliable choice for process control environments that require consistent analog performance and fast response.
It is widely used in manufacturing automation, energy systems, and process industries where accurate analog signal delivery is essential for maintaining system stability and production quality.
Technical Specifications
Parameter
Details
Manufacturer
GE Fanuc / Emerson
Series
VersaMax PLC System
Model Number
IC200ALG325
Module Type
Analog Output Module
Output Channels
8 single-ended channels
Output Signal Range
-10.24 VDC to +10.24 VDC or 0–10 VDC
Resolution
13-bit precision
Update Rate
10 ms
Output Grouping
Single group
Field Power Requirement
External 18–30 VDC supply
Backplane Power
5 VDC logic supply
Backplane Current
~50 mA
Isolation
250 VAC continuous / 1500 VAC for 1 minute
Diagnostics
FLD PWR and OK LED indicators
Output Behavior
Configurable fail-safe / last state hold
Operating Temperature
0°C to 60°C
Applications
The IC200ALG325 is commonly used in industrial automation systems requiring multi-channel analog control outputs, including:
Process control systems (flow, pressure, temperature loops)
Valve and actuator positioning control
Industrial drive and motor control interfaces
Energy and utility control systems
SCADA and distributed control systems (DCS)
It is particularly effective in systems where multiple analog signals must be generated simultaneously with stable precision and minimal delay.
Advantages
8-Channel High-Density Output Design
Reduces wiring and saves cabinet space.
High-Resolution 13-bit Output Accuracy
Ensures smooth and precise analog control.
Fast 10 ms Update Performance
Suitable for real-time industrial control loops.
Flexible Voltage Output Range
Supports both bipolar and unipolar configurations.
Industrial-Grade Isolation (1500 VAC)
Protects PLC system from electrical disturbances.
Reliable Fail-Safe Behavior
Supports last-state hold for process stability.
Technical FAQs
1. What is the IC200ALG325 used for?
It is used to generate analog voltage control signals from a PLC to field devices.
2. How many output channels does it have?
It provides 8 analog output channels.
3. What is its output range?
-10.24 VDC to +10.24 VDC or 0–10 VDC.
4. What is its resolution?
13-bit resolution for precise control.
5. What is its update rate?
Approximately 10 ms.
6. Does it require external power?
Yes, 18–30 VDC field power is required.
7. What is its weight?
Approximately 0.28–0.63 kg.
8. What devices can it control?
Valves, actuators, drives, dampers, and industrial controllers.
9. What happens during power loss?
It can hold last output or switch to a default state depending on configuration.
10. Why is it important in automation systems?
Because it ensures stable, accurate analog control signals for industrial process regulation.
