GE IC200CHS014 Interposing Thermocouple Terminal Module
GE IC200CHS014 Interposing Thermocouple Terminal Module
0.0
Points
Brand:GE Fanuc PLC Item No.:GE IC200CHS014 Product Origin:USA Product Dimensions:110 x 105 x 70 mm Product Weight:0.23 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The GE IC200CHS014 is a specialized interposing terminal module within the VersaMax I/O family, purpose-built for thermocouple signal integration. Unlike standard carriers, this module enhances measurement accuracy by incorporating cold junction compensation directly at the wiring interface. Designed for precision-driven environments, it provides a seamless bridge between field thermocouple wiring and connector-style I/O carriers, ensuring stable and reliable temperature data acquisition in critical industrial processes.
Technical Specifications
Parameter
Details
Model Number
IC200CHS014
Product Type
Interposing Thermocouple Terminal Module
Series
VersaMax
Terminal Type
Box-style (36 terminals)
Function
Thermocouple cold junction compensation
Mounting
DIN rail
Wire Size
0.36 – 2.1 mm² (single), up to 0.86 mm² (dual)
Operating Temperature
-40°C to 60°C
Storage Temperature
-40°C to 85°C
Certifications
UL, CE, CUL
Dimensions
Approx. 110 x 105 x 70 mm
Weight
Approx. 0.23 kg
Recommended Related Models
IC200CHS003 Connector I/O Carrier
IC200CBL1xxx Connection Cables
IC200ACC313 DIN Rail Clamp
IC200ALG240 Analog Input Module
IC200MDL650 Digital Input Module
Popular GE VersaMax Modules
IC200CPU001 CPU Module
IC200PWR001 Power Supply Module
IC200ERM002 Expansion Receiver
IC200ALG320 Analog Output Module
IC200MDL940 Relay Output Module
Application Areas
The IC200CHS014 is widely applied in industries where precise temperature monitoring is essential. Typical use cases include process control systems, chemical plants, power generation facilities, and food processing lines. It is particularly valuable in applications involving thermocouples, where accurate signal conditioning and compensation are required to maintain process integrity. Its flexible mounting options allow integration into both centralized and distributed control architectures.
Key Advantages
This module delivers a significant upgrade in temperature measurement accuracy thanks to its built-in cold junction compensation. By reducing external compensation requirements, it simplifies system design and minimizes wiring complexity. The robust terminal structure supports secure connections, even in high-vibration environments. Additionally, its compatibility with VersaMax systems ensures smooth integration and scalability, making it a dependable choice for both new installations and system upgrades.
Technical FAQs
What is the primary function of IC200CHS014?
It provides an interface for thermocouple wiring with built-in cold junction compensation.
How many terminals does this module have?
It includes 36 box-style terminals for flexible wiring.
Can it be mounted separately from the I/O carrier?
Yes, it can be mounted on the same or a separate DIN rail.
Does it improve temperature measurement accuracy?
Yes, the integrated thermistor enables precise compensation.
Is it compatible with all VersaMax carriers?
It is designed specifically for connector-style I/O carriers like IC200CHS003.
What industries commonly use this module?
Process industries such as energy, chemical, and manufacturing.
Does it support hot insertion?
Yes, compatible systems allow module replacement without disrupting operations.
What type of wiring does it support?
Both solid and stranded copper wires within specified sizes.
Is additional protection included for terminals?
Yes, it features a protective cover for wiring safety.
What makes it different from standard I/O carriers?
It integrates thermocouple compensation, enhancing measurement reliability.
