GE IC200MDD841 VersaMax High-Speed Mixed Discrete I/O Module
GE IC200MDD841 VersaMax High-Speed Mixed Discrete I/O Module
0.0
Points
Brand:GE Fanuc PLC Item No.:GE IC200MDD841 Product Origin:USA Product Dimensions:66.8 × 110 × 50 mm Product Weight:0.41 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The GE IC200MDD841 is a VersaMax mixed discrete high-speed counter I/O module designed for advanced automation tasks that require both standard digital control and high-speed signal processing. It integrates 20 discrete inputs and 12 outputs with built-in high-speed counter and pulse-handling functions, making it suitable for motion control, material tracking, and precision timing applications. In modern industrial systems, it is valued for combining standard I/O flexibility with high-speed processing capability in a single module.
Technical Specifications
Parameter
Details
Model Number
IC200MDD841
Product Type
Mixed Discrete High-Speed Counter I/O Module
Series
VersaMax
Inputs
20 × 24 VDC positive logic
Outputs
12 × 24 VDC (configurable)
Total I/O Points
32 (configurable mix)
High-Speed Counters
4 Type A counters
Pulse Processing Speed
Up to 80 kHz
PWM / Pulse Functions
PWM, pulse train, ramping pulse train
Input Voltage
24 VDC (18–30 VDC range)
Output Rating
Up to 0.5 A per point
Backplane Power
5 VDC (~30 mA)
External Field Power
Required for outputs
Isolation
Limited (no per-channel isolation)
Status Data
Up to 13 words diagnostic data
LED Indicators
Power, OK, field status, channel status
Operating Temperature
0°C to 60°C
Dimensions
66.8 × 110 × 50 mm
Weight
~0.17–0.41 kg
Recommended Related Models
IC200CPU002 VersaMax CPU Module
IC200CHS003 I/O Carrier Base
IC200PWR102 Power Supply Module
IC200ERM002 Expansion Receiver Module
IC200MDL750 Digital Output Module
Popular VersaMax High-Speed & Mixed I/O Modules
IC200MDD840 Mixed Discrete I/O Module
IC200MDL640 Digital Input Module
IC200MDL740 Relay Output Module
IC200ALG240 Analog Input Module
IC200GBI001 Genius Network Interface
Application Scenarios
The IC200MDD841 is widely used in precision automation systems requiring high-speed signal processing and mixed I/O control. Common applications include packaging machines, conveyor tracking systems, material handling automation, labeling systems, and light motion control setups. Its high-speed counter capability makes it especially useful for applications involving encoders, tachometers, or pulse-based position feedback.
Key Advantages
This module delivers a strong combination of speed, flexibility, and compact integration. Its ability to handle both standard digital I/O and high-speed counter functions reduces the need for additional specialty modules, simplifying system design. The 80 kHz pulse processing capability enables accurate tracking of fast-moving mechanical processes. Configurable outputs support PWM and pulse train functions, making it suitable for basic motion control tasks. LED diagnostics improve maintenance efficiency by providing real-time system status feedback. Overall, it offers a cost-effective way to add high-speed functionality to VersaMax systems without increasing footprint.
Technical FAQs
What is the main function of IC200MDD841?
It provides mixed digital I/O with integrated high-speed counter and pulse control functions.
How many inputs and outputs does it have?
20 inputs and 12 outputs (configurable).
What is the maximum counting speed?
Up to 80 kHz pulse input processing.
Does it support motion control?
Yes, basic PWM and pulse train outputs can support simple motion tasks.
Is it isolated?
No, it does not provide full channel-to-channel isolation.
What voltage does it use?
24 VDC field I/O with 5 V backplane logic power.
Does it require external power for outputs?
Yes, output loads require external field power supply.
What makes it different from standard I/O modules?
It integrates high-speed counter and pulse functions in addition to standard I/O.
What industries use it most?
Packaging, manufacturing automation, conveyor systems, and material handling.
Why is it still widely used?
Because it combines high-speed functions and standard I/O in one compact, cost-efficient module.
