The GE IC200UEM001 is an Ethernet communication option module designed for the VersaMax Micro PLC platform, enabling seamless integration between PLC systems and industrial Ethernet networks. It is widely used to connect controllers to SCADA systems, HMIs, and supervisory networks, supporting real-time data exchange and remote monitoring in modern automation architectures.
This module is especially valuable when upgrading legacy VersaMax Micro systems into networked, data-driven industrial environments without replacing the existing PLC hardware.
Technical Specifications
The IC200UEM001 focuses on high-speed communication and reliable industrial networking.
| Parameter | Specification |
|---|---|
| Module Type | Ethernet Communication Module |
| Series | GE VersaMax Micro |
| Network Interface | 10/100 Mbps Ethernet |
| Connector | RJ45 |
| Protocols | SRTP, Modbus TCP |
| Function | PLC networking, SCADA integration |
| Memory | 512 KB Flash / 256 KB RAM |
| Processor | 48 MHz communication processor |
| Communication Mode | Full duplex |
| Configuration | Via PLC programming tools |
| Operating Temperature | -25°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | Up to 95% non-condensing |
Physical Dimensions & Weight
| Item | Value |
|---|---|
| Dimensions (H × W × D) | 76 × 90 × 50 mm |
| Weight | 0.95 kg |
