The GE 8602-FT-ST is a standard field terminal module designed for the PAC8000 I/O system, providing a secure and efficient interface between field devices and I/O modules. It acts as the physical connection layer, allowing field wiring to be directly terminated without additional terminal blocks.
Engineered for both general-purpose and hazardous industrial environments, this module delivers dependable connectivity, simplified maintenance, and high installation efficiency—making it an essential component in modern distributed control systems.
Technical Specifications
The 8602-FT-ST focuses on wiring integrity, safety, and modular system integration.
| Parameter | Specification |
|---|---|
| Module Type | Field Terminal Module |
| Series | GE PAC8000 |
| Function | Field wiring interface for I/O modules |
| Supported Channels | Up to 8 channels |
| Connection Type | Screw clamp terminals |
| Wire Size Range | 0.5–2.5 mm² (20–14 AWG) |
| Voltage Rating | Up to 250 V |
| Max Current per Channel | Up to 5 A |
| Fuse Protection | Replaceable fuse per channel (typical 2A) |
| Mounting Method | Snaps onto carrier / DIN rail system |
| Compatibility | PAC8000 I/O modules and carriers |
| Safety Features | Mechanical keying, labeling strip |
| Operating Temperature | -40°C to +70°C |
| Humidity | 5–95% non-condensing |
The module enables direct field wiring and supports modular replacement without disturbing adjacent components.
Physical Dimensions & Weight
| Item | Value |
|---|---|
| Dimensions (H × W × D) | 168 × 42 × 37 mm |
| Weight | 0.11 kg |
