The Bently Nevada 3500/62 136294-01 Isolated I/O Module with Internal Terminal delivers dependable process signal interfacing for critical industrial monitoring systems. By combining effective signal isolation with a compact internal terminal design, it enhances measurement reliability and simplifies installation. As part of the trusted 3500 platform, this module supports accurate process monitoring, improved system resilience, and long-term operational confidence.

Technical Specifications

Specification	Detail
Model Number	3500/62 136294-01
Module Type	Isolated I/O Module with Internal Terminal
Signal Type	Isolated analog process I/O
System Compatibility	Bently Nevada 3500 system
Mounting Method	3500 rack-mounted
Dimensions	241.3 x 24.4 x 99.1 mm
Weight	0.2 kg
Operating Environment	Continuous industrial operation

Recommended Related Models

Bently Nevada 3500/62 Process Variable Monitor
Bently Nevada 3500/61 Temperature Monitor
Bently Nevada 3500/22M Transient Data Interface

Popular Related Models

Bently Nevada 3500/40M Preamplifier Monitor
Bently Nevada 3500/50M Tachometer Module
Bently Nevada 3500/53 Overspeed Detection Module

Applications

The Bently Nevada 3500/62 136294-01 Isolated I/O Module is designed to provide safe and reliable signal interfacing for process variable monitoring within the 3500 machinery protection system. With built-in isolation and internal terminals, it is well suited for applications requiring stable transmission of analog process signals such as pressure, flow, level, and temperature. This module is widely used in turbines, compressors, pumps, motors, and auxiliary process systems across power generation, oil & gas, petrochemical, and heavy industrial environments.

Advantages

Built-In Signal Isolation: Protects the monitoring system from electrical noise and ground loops.
Internal Terminal Design: Provides clean wiring layout and improved panel organization.
Optimized for Process Variables: Ideal for analog inputs in industrial monitoring applications.
Seamless 3500 System Integration: Designed specifically for Bently Nevada 3500 racks.
Reliable Continuous Operation: Maintains signal accuracy under demanding plant conditions.

Technical FAQs

What is the primary function of this I/O module?
It provides isolated analog I/O for process variable monitoring.
Why is signal isolation important?
Isolation prevents electrical interference and improves overall measurement accuracy.
Which terminals are used on this module?
It uses internal terminals for streamlined wiring within the rack.
Is this module compatible with the 3500/62 monitor?
Yes, it is designed to operate with the Bently Nevada 3500/62 Process Variable Monitor.
What types of signals does it support?
Analog process signals such as pressure, flow, level, and temperature.
Can it operate continuously?
Yes, it is designed for 24/7 industrial operation.
What are the physical dimensions and weight?
Dimensions: 241.3 x 24.4 x 99.1 mm, Weight: 0.2 kg.
Is it suitable for harsh industrial environments?
Yes, built to maintain stable performance in electrically noisy conditions.
How is it installed?
Installed directly into a Bently Nevada 3500 rack as an I/O module.
What maintenance is required?
Minimal, typically limited to routine inspection and system verification.
